Moulton SST
Moulton SST
Please note that Moulton bicycles are all handmade in England to order and at present we have limited stock. Current stock can be viewed HERE. Current lead times for new orders can be found HERE.
WE DO NOT SHIP OUTSIDE MAINLAND GB.
A step on from the TSR, the SST features a new chainstay ‘X-brace’ frame reinforcement, with an adjustable mudguard mount. Frame weight has been reduced with a round-tapered chainstay, lighter rear fork upright tube, and smaller stirrup block height. Another superbly versatile model.
NEW FOR 2023
SST 22 WITH SHIMANO 105 NOW AVAILABLE WITH V OR CALIPER BRAKES
SST 11 WITH SHIMANO ALFINE NOW AVAILABLE WITH V OR CALIPER FRONT BRAKE
We encourage customers to collect their bikes from our shop in Stratford-upon-Avon so we can fully assemble the bike and adjust it to fit perfectly. We can also deliver to any UK address for £40. Bikes are boxed and need a small amount of assembly on arrival – usually the pedals need to go on and the handlebars need straightening – We can talk you through this if needed.
Additional Information
The Moulton SST possesses all the essential Moulton features for performance and comfort – space-frame construction, small wheels and full suspension – all encompassed within the iconic and inimitable Moulton architectural aesthetic. Engineered for a smooth and efficient riding experience, the Moulton space-frame is uniquely separable for ease of transportation and stowage. A step on from the TSR, the SST features a new chainstay ‘X-brace’ frame reinforcement, with an adjustable mudguard mount. Frame weight has been reduced with a round-tapered chainstay, lighter rear fork upright tube, and smaller stirrup block height. The SST has stainless steel drop-outs front and rear. Another superbly versatile model. With a full range of optional racks, bags and mudguards, there is a TSR for every use – sportive riding, touring, commuting and leisure. Every SST is hand-built in England by highly skilled craftsmen.
SST Features
Wheel Size: 20"
Frame: Fillet-brazed multi-tube space-frame construction in Columbus Spirit and Reynolds 525 CrMo steels. Hairpin construction.
Fork: TIG-welded CrMo fork with hand-brazed floating stirrup.
Front Suspension: Moulton Leading Link
Rear Suspension: Moulton Monosphere
Separability: Separates into two halves via removal of a centre kingpin
Frame Finish: Powder coat
Front Carrier: Fits optional Moulton Front Pannier Carrier or Front Platform Carrier
Rear Carrier: Fits optional Moulton SST Rear Day Bag Carrier or Moulton SST Rear Luggage Carrier
Options: Mudguards. Bottle cage.
SST 11 Shimano Alfine Specification
Colours: Black, Forest Green, Britannia Red or Airforce Blue (optional paint colours +£80 HERE)
Headset: Tange Seiki RDC 1" sealed
Front hub: Moulton custom alloy forged 28h
Rear hub: Shimano Alfine 11 speed 32h silver
Spokes: Sapim Laser butted front/PG rear
Rims: Moulton MT20, Black, CNC brake track
Tyres: Schwalbe One 28-406 (Kevlar band)
Tubes: Schwalbe 20" presta
Crankset: Shimano Alfine 45t w/chainguard
Bottom bracket: Shimano Hollowtech II
Brake levers: Tektro FL750
Brakes: 57 caliper front / TRP Spyre disc rear
Gear levers: Shimano Alfine rapidfire
Cassette: 17T
Chain: Connex 1/2 x 3/32" stainless
Pedals: MKS Promenade q/r
Seatpost: 31.6 forged Aluminium, layback head
Saddle: Brooks C17 Black
Handlebar stem: AL ahead stem (90, 110 or 135mm)
Handlebar: Flat: Brooks Cambium Ergonomic Black
Grips: Brooks Leather slender
Gear range: 26-106" (45/17)
Frame size: Suitable for inside leg 27-36"
Weight (no pedals): 11.8kg
Mudguard clearance: Up to 32mm tyre section
SST 22 Campagnolo Centaur Specification
Colours: Black, Forest Green, Britannia Red or Airforce Blue (optional paint colours +£80 HERE)
Headset: Tange Seiki RDC 1" sealed
Front hub: Moulton custom forged 28h silver
Rear hub: Moulton custom forged 28h silver
Spokes: Sapim Laser/Force butted (differential)
Rims: Moulton MT20, Black, CNC brake track
Tyres: Schwalbe One 28-406 (Kevlar band)
Tubes: Schwalbe 20" presta
Crankset: Campagnolo Centaur Ultra-Torque Silver
Bottom bracket: Campagnolo Ultra-Torque
Brake levers: Campagnolo Centaur Silver
Brakes: Tektro R539 DP 57 calliper
Gear levers: Campagnolo Centaur Silver
Front mech: Campagnolo Centaur Silver
Rear mech: Campagnolo Centaur Silver
Cassette: Moulton 10-32
Chain: Connex 11sX
Pedals: none supplied
Seatpost: 31.6 CNC Aluminium, in-line (lightweight)
Saddle: Fizik Antares
Handlebar stem: AL ahead stem (90, 110 or 135mm)
Handlebar: Deda Speciale classic drop (44 or 42)
Bar tape: Brooks Cambium Rubber
Gear range: Tour = 21-96" (52/36); Sport = 26-107" (58/44)
Frame size: Suitable for inside leg 27-36"
Weight (no pedals): 10.5 kg / 23 lb
Mudguard clearance: Up to 28mm tyre section
SST 22 Shimano 105 Specification
Colours: Black, Forest Green, Britannia Red or Airforce Blue (optional paint colours +£80 HERE)
Headset: Tange Seiki RDC 1" sealed
Front hub: Moulton custom forged 28h silver
Rear hub: Moulton custom forged 28h silver
Spokes: Sapim Laser/Force butted (differential)
Rims: Moulton MT20, Black, CNC brake track
Tyres: Schwalbe One 28-406 (Kevlar band)
Tubes: Schwalbe 20" presta
Crankset: Shimano 105 53/39
Bottom bracket: Shimano Hollowtech II
Brake levers: Shimano 105
Brakes: Tektro R539 DP 57 calliper
Gear levers: Shimano 105
Front mech: Shimano 105
Rear mech: Shimano 105
Cassette: Moulton 10-32
Chain: Connex 11sX
Pedals: none supplied
Seatpost: 31.6 CNC Aluminium, in-line (lightweight)
Saddle: Fizik Antares
Handlebar stem: AL adjustable stem 110 / 31.8
Handlebar: GB Carter Bar (drop)
Bar tape: Brooks Cambium Rubber
Gear range: 23-98" (53/39 only)
Frame size: Suitable for inside leg 27-36"
Weight (no pedals): 10.8 kg / 23.7 lb
Mudguard clearance: Up to 28mm tyre section
